Model No: JCOS-A5 | 8 | 10
High-performance sport LED boarding
-Robust structure
-Flexible installation
-High brightness display
-Wide viewing angle
-Waterproof and dustproof
-Adjustable cabinet viewing angle
-Flexible installation
-High brightness display
-Wide viewing angle
-Waterproof and dustproof
-Adjustable cabinet viewing angle
Pixel pitch :
Cabinet Size :
Quantity :
Subscribe to our Newsletter
Sport LED Boarding
A sport LED boarding is a large display designed to provide visual information and entertainment to the audience inside the stadium. It can display a variety of content such as live sports scores, player statistics, advertising, replays of key moments in the game, animations and promotional messages.
The sport LED boarding is made up of lots of LED modules that are connected together to form one big screen.
Sport LED boarding displays are often high-resolution to ensure clear and vivid visuals from a distance.
Sport LED boarding are also built to be durable and weather resistant to withstand a variety of environmental conditions and the rigours of outdoor use in a stadium environment.
Product Parameters
| Pixel pitch | 5mm | 8mm | 10mm |
| Module size | 320mm*160mm | ||
| Scan mode | 1/8scan | 1/5scan | 1/2scan |
| Package resolution | 64dots(W)*32dots(H) | 40dots(W)*20dots(H) | 32dots(W)*16dots(H) |
| Color Configuration | SMD 3 in 1 1R1G1B | ||
| Control system | Nova star | ||
| Input Voltage | AC220V/50Hz or 110V/60Hz | ||
| Average Power consumption | 330W/m2 | ||
| Cabinet size | 960mm*960mm | ||
| Pixel denity | 40000dots/m2 | 15625dots/m2 | 10000dots/m2 |
| Material | Die-casting Alumium | ||
| LED | Kinglight/Nationstar | ||
| Refresh Rate | 1920/3840Hz | ||
| Colors | 549Billion | ||
| Brightness | ≥6000cd/m2 | ||
| Life span | ≥100,000hours | ||
| IP rating(Front/Rear) | IP65 | ||
| Min.Viewing Distance | ≥5m | ≥8m | ≥10m |
| View Angle | 160°（W）120°（H） | ||
| Temperature-operating | -30℃~+60℃ | ||
| Humidity-operating | 10%~95% | ||
| Source compatibility | AV,DVI,HDMI,SDI,S-Video,DP etc | ||
| Thickness | 85mm | ||
Sport LED Boarding Features
(1) Lightweight and Slim Cabinet:Die-cast aluminium sportcabinet weighs only 28kg, 30% lighter than traditional waterproof cabinets. The thickness of the cabinet is only 120mm, making it easy to install and transport.
(2) 0-90° Adjustable Support Bracket:The viewing angle of the cabinet is 60-90 degrees, providing high flexibility for optimal viewing. The LED boarding can be adjusted for the best visibility.
(3) Rubber Module Face Shield and Protective Top Cover:LED modules of sport LED boarding come with rubber masks for impact protection. The soft top cover design ensures player safety even during collisions.
(4) IP65 Protection and High Brightness: Sport LED boarding has IP65 waterproof design,suitable for indoor and outdoor use, ensuring durability in harsh environments. The sport LED boarding offers high brightness of 6000-7500nits.
(5) Wide Viewing Angles: Sport LED boarding have a large viewing angle, allowing the audience in different positions within the stadium to have a good viewing experience. Whether the audience is sitting on the stands or standing at other locations in the stadium, sport led boarding can clearly see the content displayed on the screen without missing any important information.
(6) Flexible Installation and Splicing: Sport LED boarding can be installed in various ways, such as wall-mounted,column-mounted, and hanging installation, according to the architectural structure and design requirements of the stadium. Meanwhile, sport LED boarding can also be easily spliced into various shapes and sizes to meet the individualized layout requirements of different stadiums and achieve a perfect integration with the stadium environment.
（7）Rapid Information Update and Interactivity: Sport LED boarding can accurately update the game scores, player information, event dynamics, and advertising content in a short time, ensuring that the audience can obtain the latest information promptly. In addition, sporting LED boarding support various interactive forms, such as real-time voting and interesting games, enhancing the audience's sense of participation and experience and adding more fun to the sports events.
